VITAL INFORMATION

Assembly instructions for multi-enclosure batteries:

1. Ensure that the battery is switched off.

2. Connect the bus bars.

3. Connect the 3-pin COM cables.

4. Connect the 4-pin DATA cable.

5. Check the fuse(s).


Setpoints for voltage-based setup:

For installations that exclude serial/CAN communication, set the following values:

	13V	26V	39V	52V
V(high set) / Bulk / Absorb	14.1V	28.1V	42.1V	56.2V
V(float)	13.9V	27.8V	41.6V	55.5V
V(reconnect)	12.8V	25.6V	38.4V	51.2V
V(low set)	12.3V	24.5V	36.8V	49V

IMPORTANT: To ensure that your battery remains in optimum operating condition, charge the battery at least every 3rd day to 100% state-of-charge and verify that each cell’s voltage is between 3.5V ~ 3.65V.

Connecting batteries in parallel:

1. If capacities differ, ensure that Multicap™ requirements are met.

2. Ensure that the latest firmware version is installed on each battery.

3. Ensure that each battery is fully charged before connecting.

4. The length & diameter of each interconnecting cable should be the same.

5. Connect to the inverter/load from opposite ends of the battery string.


Support:

For any technical assistance, please log a ticket on our support system.

https://www.bluenova.co.za/contact-us/support/

Supporting materials:

Supporting documents, latest firmware, and manuals can be found on our website under the knowledge base: https://desk.zoho.com/portal/bluenova/home

Following installation, please complete the Online Product Registration Form. This can be found online at:  https://www.bluenova.co.za/product-registration/

Contact information:

BlueNova Technical Support    +27(0)21 205 2000 / support@bluenova.co.za

We value your feedback! For suggestions on how we can improve our products and services, please email BlueNova Customer Care at enquiries@bluenova.co.za
