Guide to a healthy and happy battery



Dear BlueNova Energy client, the following guide will assist you to maintain your battery in a healthy manner and to prevent unnecessary maintenance on your system.


Directions


  1. Please charge battery at least every 3rd day to 100% SOC.
  2. Make sure on the battery OLED display the pack voltage is above 56.1v.


  1. Confirm that all the cells are above 3.5V but not higher that 3.65v.




  1. All cells must be balanced (voltage range close to each other).











Setpoints for voltage-based setup:


For installations that exclude serial/CAN communication, set the following values:



13V

26V

39V

52V

V(high set) / Bulk / Absorb

14.1V

28.1V

42.1V

56.2V

V(float)

13.9V

27.8V

41.6V

55.5V

V(reconnect)

12.8V

25.6V

38.4V

51.2V

V(low set)

12.0V

24.0V

36.0V

48V


Notes:


  1. If you have a cell with a voltage that is lower that the rest of your cell can lead to lost in capacity or Vcell low errors.
  2. If you do not reach the healthy battery recommended settings please contact your installer.

Support:


For any technical assistance, please log a ticket on our support system.

https://www.bluenova.co.za/contact-us/support/



Supporting materials:


Supporting documents, latest firmware, and manuals can be found on our website under the knowledge base.(BlueNova-contact us-support-login-knowledgebase)

https://desk.zoho.com/portal/bluenova/home


Contact information:


BlueNova Technical Support +27(0)21 205 2000 / support@bluenova.co.za

We value your feedback! For suggestions on how we can improve our products

and services, please email BlueNova Customer Care at feedback@bluenova.co.za
